Khớp Nối Nhanh Chicago Cái AMC1 Dixon Valve Air King Universal Coupling Iron Male NPT End - 1/4"

Thương hiệu: Dixon
|
Loại: Khớp Nối Công Nghiệp
|
Mã SP: TDC-TBHTTD-75
Liên hệ
Mfr #: AMC1
Xuất Sứ:
Chứng Chỉ:
Tiêu đề
Số lượng
Hotline mua hàng Gọi ngay 093 129 9618 CSKH 093 129 9618
Features:
  • Safety clip included
  • Supplied with rubber washer, part # AWR4
  • The use of an Air King safety clip or wire type retainer is necessary to ensure Air King universal couplings will not become accidentally disconnected.
  • To provide protection against coupling breakage and related hazards, Dixon recommends the use of a whip hose.
  • Pressure rating given at ambient temperature 70°F/21°C
  • Use of supplied safety clip guarantees the fittings are properly connected because the safety pin will not go through the holes in mating fittings until couplings are locked in place. Only one Air King safety clip or wire type retainer is required for each Air King universal coupling.
  • Never use any Air King coupling for steam service!
Specifications:
  • Air King meets pressure requirements as specified in A-A-59553 commercial item description superseding Mil Spec.WWC-633D.
Part Number Size Material Seal PSI Weight (Lbs)
AMC1 1/4" Iron Rubber 150 (10.20 bar) 0.5800
AMC 3/8" Iron Rubber 150 (10.20 bar) 0.5600
AM3 1/2" Iron Rubber 150 (10.20 bar) 0.5500
AM8 3/4" Iron Rubber 150 (10.20 bar) 0.6000
AM13 1" Iron Rubber 150 (10.20 bar) 0.5300
ABC1 1/4" Brass Rubber 150 (10.20 bar) 0.6550
ABC 3/8" Brass Rubber 150 (10.20 bar) 0.6400
GAB3* 1/2" Brass Rubber 150 (10.20 bar) 0.4300
GAB8* 3/4" Iron Rubber 150 (10.20 bar) 0.4700
GAB13 1" Brass Rubber 150 (10.20 bar) 0.4900
RAMC 3/8" 316 Stainless Steel Rubber 150 (10.20 bar) 0.5250
RAM3 1/2" 316 Stainless Steel Rubber 150 (10.20 bar) 0.5600
RAM8 3/4" 316 Stainless Steel Rubber 150 (10.20 bar) 0.6500
RAM13 1" 316 Stainless Steel Rubber 150 (10.20 bar) 0.5500
